Large Quantity Wall Transformer Deals

10.5VAC/714MA. Ideal 5A-3230. UL. Toy transformer. Molex type connector. 10,000 available.

20VAC/700MA. Microbridge WP571420G. UL. Input 120VAC 60Hz. 30W. Two screw terminal output. Three prong AC plug. Hold down tab. 4"L x 2-1/2"W x 2-1/8"H. Individually cartoned. 15,000 more available.

IF YOU CAN'T FIND WHAT YOU NEED ... Contact us by fax, phone, or e-mail for our help.

13.5VDC/1AMP. MK-1351000. Input 120VAC/60 Hz (20W). UL. Class 2. 6 ft cord terminated in a 2.1/5mm barrel jack w/9mm shank. Ctr. neg. 2-7/8"L x 2-3/16"W x 1-3/4"H. Made in Taiwan. Individually cartoned.

7.5VDC/500MA & 5VDC/1.5A. Po Trans (ITE) UP01222020. Type 402 0034-US. BML 161 164/1. Input 100-240VAC 50-60Hz. UL/CSA. 2-3/4"L x 1-7/8"W x 1-5/8"H. Output to 5 pin mini din plug on a 5' cable. Made in Taiwan. 25,000 available at press time! POR.

20VDC/1.5AMP. JOD-57U-03. 115VAC. UL/CSA. Table top unit. 2.5/5.5mm barrel jack with 9mm shank. Center positive. 2.5"W x 3.5"L x 2.25"H. Made in Taiwan. Class 2. Individually cartoned.

6VDC/100MA. AT&T #24392 "trickle charger" UL/CSA. Small size; 2" x 1-1/4" x 1-1/4". Output cord terminated in 3.5/1.3mm barrel jack with 7mm shank. Center positive.

12VDC/4.16AMP. Symbol Technologies p/n TR9CE4100LCP-A. Model 50-14000-075. UL/CSA plus approval for 4 other countries (CE). Level 3. Input 100-240VAC/50/60Hz. Made in Taiwan. 5-3/4"L x 2-1/2"W x 1-1/2"H. Standard IEC 3-prong socket for line cord. 5' output cord is terminated in 2.5/5.5mm barrel jack with 10mm shank. Center positive. Weight is 1 lb. Supplied less line cord.

5.7VDC/700MA. Philips 1128. Switching type wall transformer (also marked "fast travel charger"). Philips model 1128/SKU24769 Input; 90-132VAC 60Hz. UL/CSA. Class 2. Tiny size; 2-7/8"L x 2"H x 1-3/8"W. Made in China. Output cable is terminated in what appears to be a 3.5/1.1mm barrel jack. Center positive. 15,000 more available.

Yes it is possible to change the connector on a wall transformer. We can refer you to a company that can mold on new connectors to any one of our wall transformers to exactly match the fit and polarity you need. Calculate that the added cost will be in the area of $1.50/unit. Minimum quantity would be 100/type. Call, fax or e-mail for details.

4.7VDC/2 AMPS. Philips 26092. "Fast travel charger". Input; 95-240VAC, 47 to 63Hz. UL/CUL. USA style AC prongs. (Slide on prongs are exchangeable) Small size; 4"L x 2-1/4"W x 1-1/4"H. 7 conductor output cable is 3/16" diameter and terminated in special Philips style flat plug. 50/carton. Currently equipped with USA wall prongs - but can be changed to foreign prongs.

16VAC/500MA. New stock - but bulk packed - not in nested cartons. Northern Telecom AO619627. Input 117/120 VAC 50/60 Hz (13W). UL/CSA. (Also marked Anoma Electric model AD-7502D (made exclusively for Northern Telecom) Class 2. Popular for telephone use. 2"W x 2-3/8"L x 1-5/8"H. Terminated in 2.5/5mm right angle barrel jack on 12ft cord. BRAND NEW NORTHERN TELECOM INVENTORY! Made in China.

23VAC/1.25A center tapped. Aura I-143-BX002. UL/CSA. Class 2. Capable of 11.5VAC/1.25A each side of CT. Output cable terminated in 3 pin Din plug. Built in thermal fuse in secondary. Open circuit voltage 27VAC max. 3-1/2"L x 2-1/2"W x 2-1/8"H. Made in China.

15VDC/1AMP. Labtec model AD-SS-2. CSA/UL. Light grey. Class 2. Made in China. 2.1/5mm barrel jack. Center negative. 3-5/8"L x 2-3/8"W x 2-1/4"H.

9VDC/300MA. Vtech Model N-3515-0930-DC. UL/CSA. p/n 26-0133-03-04. Made in China. 2"L x 1-3/8"H x 1-5/8"W. Output cord terminated in 3.5/1.3mm right angle barrel jack with 9mm shank. Center positive. Marked "Class 2 Component Telephone Power Supply".

9VDC/300ma. Lucent Technologies 9105. White. UL/CSA. Class 2. 2-1/4"L x 1-3/8"H x 1-3/4"W. Terminated in 3.5/1.3mm right angle barrel jack. Center pos. Marked "Component Telephone Power Supply".

7.5VDC/700MA. Radio Shack 43-5508/5809. Input 120VAC 60Hz (14W) Regulated. UL. Class 2. Marked "Component Telephone Power Supply". Made in China. 3-3/8"L x 2-3/8"W x 1-15/16"H. 6 ft output cable terminated in 2.1mm barrel jack. Black, Center positive. 10,000 available.

12VDC/300MA. UL/CSA. SPN4139A/AD1230. 2-1/8"L x 2"W x 1-1/2"H. Class 2. Made in China. 6' black zip cord terminated in 1.3/3.5mm barrel jack with 11mm shank. Center positive.

6VAC/1.5AMP Audiophile AA-061A5. 120VAC/60Hz, 15W. UL/CSA. 2-1/4"L x 1-5/8"H x 2"W. Class 2. Made in Taiwan. 6' cord terminated in 2.5/5.5mm barrel jack with 12mm shank.

12VDC/200MA. Radio Shack 43-5512/5513. UL. Marked "Component Telephone Power Supply". 2-1/8"L x 1-3/8"H x 1-1/2"W. Class 2. Made in China. Terminated in 2.1/5.5mm right angle barrel jack with a 11mm shank. Center Positive.

7.5VDC/1200MA. Leader Electronics p/n 1135. Model 4807512RO3CT. UL/CSA. 2-1/2"L x 2"H x 2"W. Output cord terminated in 2.1/5.5mm right angle barrel jack with 10mm shank. Center positive. Made in China. Class 2. Only 1 left.

5.7VDC/840MA. Switching type wall transformer. Philips model 10PS306/17 (3122 427 21031) Input; 100-240VAC 50/60Hz. (Standard USA AC prongs) UL. Class 2. Tiny size; 2-7/8"L x 2"H x 1-3/8"W. Made in Portugal. Output cable is terminated in what appears to be a 3.5/1.1mm barrel jack. Center positive. 50,000 available.

17.8VAC/600MA (CT) & 9VDC/550MA (5VA) Excel PSU502 for CATV use. UL. Unusual unit in that it has a 120VAC 500 watt AC outlet on the side of the transformer. 3-1/8"L x 2-1/4"W x 2-1/4"H. Has wall mounting lock tab. Class 2. Made in Taiwan. Output cable terminated in 5-pin standard 180 degree male Din plug. 9000 available. Some of these could be cosmetically blemished due to poor storage. POR

10.3VAC/1.65 Amp. KTI Corp (Tel; 214-234-4812) #148-0024-001. UL. 3-1/8"L x 2-3/8"W x 2-1/2"H. Has wall mounting lock tab. Has 5 foot - 3 conductor input cable terminated in 3-prong grounded AC plug. The 5' output cable is terminated in a 3-pin molex connector. 12,000 available. Some of these could be cosmetically blemished due to poor storage. POR
