Miscellaneous Switches

We can supply most requirements for quantity purchases of switches by Cutler Hammer, Grayhill, MicroSwitch, and most other major suppliers. Obsolete and proprietary parts, too. Vast inventory resources. MIL-spec, too! E-mail your quantity requirements today.

ITE Heavy Duty Saftey Switch PN# NF351H. They are 30 amp, 600 volt, 3 pole, non-fuseable in a NEMA 12 enclosure. Brand new in mint condition ITE boxes. 45 available.

Long, single side "ON" travel (approx .27") offers broad design flexibility. Dust-proof and sliding contact design offer high reliability. Smooth switching (operating force 70gf max) with minimum load to mechanism. Ideal as position sensor for CD players, laser disk, VCRs, R/C models, etc. As low as 0.45 each in 100k quantity!

We have available an industry specialist that is able to design and manufacture coin operated devices to your specifications. You are invited to submit your needs for quotation. To discuss this furthur contact Ted Duskes at 514-739-8723.

RF switch box originally used in a cable TV application. Front panel key lock alternately actuates two slide switches. Five removable trap modules plug into male push-on "F" connectors. Rear panel has four female "F" connectors. Size: 3" (H) x 6" (W) x 6

SPST tamper switch protects cabinet doors, hinged compartments etc. Mounts in 3/8" round hole (panel thickness up to 1/10"). The switch is normaly closed (ON) when the actator is fully extended and open (OFF) when the actuator is depressed .020" travel distance. Total actuator travel distance is 0.40". Rated 2A@125VAC & 1A @250VAC Push-On (.187") terminals. POR

Automatic Dish Switch - connect up to four receivers to two dual LNB dishes, or to one DISH 500 dish. Includes ACC SW64 Power Inserter and Power Supply.

Cisco WS-C1924-EN 24 Port 10Mb Switch, 2 100BaseTX Ports, ISL,CGMP,RMON Spare switches are pulls, being sold as-is.

We have 6PS653F160F120B switches for sale. Contact Marshall Duskes for pricing at 450-902-0489.

Standard "silent" AC wall switch. UL. 125V/15A. With mounting screws. Designed and Engineered in the USA and custom built in China.

ALCO DRM1RA switch available.

Push to make. (This can be reversed) Metal case has slip-proof bottom. Cord is 5 foot and terminated in 1/4" phone plug. Rated 1/2 amp at 125VAC. 3-1/8" x 3-3/8" x 1".

A foot switch may be used for starting and stopping small motors, keying paging systems, intercoms or two-way radio. Useful just about anywhere that a persons hands are occupied. also great for musical instruments. This SPST switch is momentary on. i.e. The circuit is completed while the switch is held down with the operators foot. Version MF795 (same price) is push-on to complete circuit, push-off to break circuit. Both switches are rated 5A/125VAC or 3A/250VAC and are supplied with a 10 foot cord, terminated in a standard 1/4" phone plug.

Heavy duty 12VDC/30 amp SP3T push-pull switch. Mounts in .375" hole. Screw terminals. 3 position action. Recommended for marine, RV and vehicular applications.

Black Box AdaptaSwitch & Omnitron Systems for sale. 85% of goods are new in the retail boxes or sealed in static bags. The other 15% are used and are not boxed in good condition. Please go to more info to view complete list. We are looking for offers on the complete lot.

Brand new inventory - in original boxes or bags. Over 210 line items... prices are negotiable and will be based on quantity.

1 x CUTLER HAMMER 16316H1630 pneumatic LP time delay switch. Specs as follows: Timing Range: 0.05 to 60 seconds, ON Delay Function: Timing begins when lever is actuated and held, OFF Delay Function: Timing begins when lever is released, Repeat Accuracy With 15 second or higher interval between timing periods: 10% of setting maximum - With less than 15 second interval between timing periods: 25% of setting maximum, 250 operations per minute maximum, Enclosure Rating NEMA 4, 13, Operating Temperature: 32 to 150F (0 to 65C), Conduit Entrance: 0.5 inch NPT, Shipping Weight: 2 pounds, UL Listed.

1 x CUTLER-HAMMER DH361URK, 600 VAC HD SAFETY SWITCH. Specifications: 30 - 1200 amperes Horsepower rated. Suitable for service entrance use. Except 1200 ampere on 480Y/277 or 600Y/347 grounded wye systems, per NEC 215-10 and 230-95, and 4-pole switches. UL listed.

2 x EMC Connectrix DS-24M2 Switches. Part number 118032296. Removed from active service. The EMC Connectrix DS-24M2 Switch provides full fabric support, true line-speed switching, fibre channel loop support, 8 to 24 port configuration flexibility and modular components for expandibility. The 2 Gb DS-24M2 can participate in a multiple-switch fabric, interconnecting hundreds of Fibre Channel ports. EMC Connectrix Switches are ideal for department or edge environments providing highly available, heterogeneous access to SAN applications, offering first class availability and management features, nondisruptive firmware upgrades, and continuous switch health monitoring. Specifications: EMC Connectrix DS-24M2 - switch - 8 ports Form Factor External Data Transfer Rate 2.12 Gbps 8 to 24 universal fibre channel ports, available in 8 port increments Ports Qty 8 Data Link Protocol Fibre Channel Communication Mode Full-duplex Remote Management Protocol SNMP, HTTP Cascade max: Up to 16 switches, 3 hops FC-FLA, FC-GS-2, FC-FG, FC-PH, FC-PH-2, FC-PH-3 Full line-speed switching, 400 MB/sec per port, full duplex Switch bandwidth: 48 Gb/sec Fabric Latency: 2 microsecond max across switch Max frame size: 2112-byte payload Classes of Service: Class 2, Class 3, Class F (Interswitch Frames) Port Types: FL_Port, F_Port, E_Port and G_Port. Self discovery based on connection type Fabric Services: Simple Name Server, Registered State Change Notification (RSCN), Alias Server (Multicast), Zoning Hot swappable: redundant power supplies, redundant cooling fans, optics Standard config in EC-1200 cabinet is from 1-12 DS2-24M2 switches. CLARiiON rackmount also available. Desktop configuration - standard. 19 in rack mounting kit available.

Vandal resistant switches - four different models. Stainless steel. SPST, DPST and momentary contact. Current rating: 12A 250VAC DP, 13A 250VAC SP Insulation resistance: >20Meg Ohms Initial contact resistance: 100Meg Ohms @ 12VDC Dielectric strength (open contacts): >1000V for 1 min. Terminal material: copper alloy Contact material: silver alloy Body material: nylon 6.6 Actuator & bezel: stainless steel Terminal type: .187" quick connect STK # TYPE ACTION MOMENTARY ACTUATOR GD123 SPST On-Off N Stainless steel GD124 DPST On-Off N Stainless steel GD125 SPST On-Off Y-On Stainless steel GD126 DPST On-Off Y-On Stainless steel

Heavy duty snap action switch with hinged roller lever. Specification: - Current rating: 15A @ 125/250V AC, 1/2A @ 125V DC, 1/4 HP @ 250V DC, 1/8 HP @ 125V AC, 1/4 HP @ 250V AC - Insulation resistance: 15 Meg ohm (Max.) - Initial contact resistance: 15 Meg ohm (Max.) - Dielectric strength: 1000V AC for 1 min. - Contact material: silver - Terminal material: brass - silver plate - Terminal type: screw Click "more info" for additional specs.

Momentary push button snap action switches. Specifications: ELECTRICAL RATINGS: - 15A, 125-250V AC 65C, UL E91973 CSA LR98589-1 - 1/2HP, 125-250V AC, UL/CSA - 15A, 250V AC T125, VDE 4715UG MATERIALS: - Operating force (Nom): 280g (10 oz) - Endurance (Mech): >10'6 operations - Flame retardancy: UL 94 V2 - Actuator: nylon 6.6 - V stainless steel - Mounting bracket: nylon 6.6 - Contacts: fine silver u gap Click "more info" for additional specs.

Higly flexible - can be used as normall on or normally off. Vandal-resistant snap action switches. Specification: - Current rating: 22A 125-250VAC 1Hp @ 65º C - Mechanical life: >10 milli ohms operations - Insulation voltage: >1250V - Tracking force: 120g - Contact material: fine silver - Terminal material: copper alloy - Body material: nylon 6.6 VO - Actuator & bezel: stainless steel - Termianal type: .250" quick connect Click "more info" for additional specs.

Old-style knife switch - great for use in science experiments. Specs: - Current rating: 300MA @50V AC, 500MA @ 6V DC - Initial contact resistance: 15MW (max.) - Terminal material: nickel plated steel - Terminal type: screw - Contact material: nickel plated steel - Base material: ABS Click "more info" for additional specs.
