Switching Power Supplies

Ibm 90X9527. delivers -12VDC@410ma, +12VDC@350ma, +5VDC@760ma, 94 watts continuous output. Model No. AA13621. GBM No. 90X9526. EC No. A79442. UL approved. Input 100- 125VAC or 200 - 240VAC. 3000 brand new units available. 1 only

Data General 2771, with CSA/UL/GS and TUV approval. Input 100 - 240VAC 50/60Hz. Outputs: 10 - 18VDC@700ma, 18VDC@2.2A. Plastic enclosure 4"W x 6.25"L x 2"H.

12VDC/4.5AMP with 5 amp surge. Regulated switching power supply. Low ripple. Power indicator light. Short circuit protection. Automatic overload and thermal cut-off. Class 2. Input; 100V to 140VAC. 60Hz. UL/CSA. 12VDC output delivered to cigarette lighter socket. 5.5' line cord terminated in non-polarized two prong AC plug. 2-1/2"W x 5-1/4"L x 1-3/4"H. Use to operate automotive equipment in the home or office. Weighs less than 1 lb. Imported for ongoing availability.

Dell 24111. Compact - only 2.125" x 4.375 x 1.5". Input 100VAC to 250VAC / 47 - 63Hz. Multiple approvals. 2.1 / 5mm right angle barrel jack. Requires IEC line cord. 5000 available.

Input; 115VAC/230VAC switchable. UL/CSA. 50/60Hz. Output; +5VDC/18A, +12VDC/4A, -12VDC/400MA, - 5VDC/300MA. Spec sheet available. Subject to prior sale. FOB India. 10 units master carton (master ctn size 23" x 19" x 19.5").

Manufactured by QPS in Israel for Magnavox Advance Product Systems. They contain several circuit boards with parts and other good items. Sorry no other spec . 228 pieces available.

5VDC/1AMP switching supply. Be-Well Electronics #ZD0001. Input; 100-240VAC, 50-60Hz. RU and TUV approved. 4-1/8"L x 2"W x 1-1/2"H. 24" output cord terminated in a 3.5/1.1mm barrel jack.

20VDC/800MA/100VAC-240VAC 60/50 Hz. Packard Bell ADP-SK3A. CSA/RU/GS. Output cable terminated in 4 pin din-type plug. 6" L x 3" W x 1-1/2" H. Requires plug in 3 conductor line cord.

30 x 79F3443 for 35/56/76 $38 ea 9 x 52G7947 for 6482 value point $75 ea 100 x 27F4166 for 30/286 55SX $17 ea 155 x 72X6669 for 8560/65/80 $13 ea 80 x 90X8626 for 8570 $14 ea 200 x 90X9366 for 8550/8550Z $15 ea Minimum order 20 assorted. All units subject to prior sale. All units tested and warranteed against DOA.

7.5VDC/2AMP. Macintosh Model M5651B (APS-20B). Input 100VAC-240VAC. Output cable terminated in what appears to be a 2.1/5mm barrel jack. Center is pos. This is a switching supply. 3-prong AC plug for England. Gray. 4"L x 2-1/4"H x 2-3/8"W. Several thousand available.

5VDC/2Amp & 12VDC/500MA. (It is possible that there are two 5VDC outputs on this transformer) LZR p/n LZASN02021A3000. Input 100-120VAC 50-60Hz. CSA. Grey. Used to power the Intel Netport Express Pro/100 print server. Wall type transformer. 2-1/2"W x 4"L x 1-1/2" Output to 5 pin mini din plug. May be slightly blemished due to poor storage.

5VDC/2Amp and 12VDC/500MA. Regal Electronics model SPA15-2512/SW. Input 100-250VAC 50-60Hz. UL/CSA/GS . Grey or whiten. Requires line cord. 2-3/4"W x 6"L x 1-1/2"H Output to 5 pin mini din plug. May be slightly blemished due to poor storage.

5VDC/1Amp & 12VDC/500MA. ITE p/n 519836-003. Input 100-250VAC 50-60Hz. UL/CSA/GS + two other approvals. Requires line cord. 2-1/2"W x 4"L x 1-1/2"H Output to 5 pin mini din plug. May be slightly blemished due to poor storage.

5VDC/2Amp & 12VDC/500MA. ITE p/n 628380. Input 100-130VAC 50-60Hz. UL/CSA. Wall type power supply. 2"W x 4-1/4"L x 1-1/4"H Output to 5 pin mini din plug. May be slightly blemished due to poor storage.

We have one units. Input: 100-240 VAC, 50/60 Hz. Output: 12V@3.3A. Switching. VDE, CSA and other approvals. HP Model F1044B. Requires standard IEC line cord.

18VDC/2 AMP. CTX ZVC36-18-K14. Input; 100 to 240VAC. UL/CSA plus 8 other foreign approvals. Tiny size only; 4-1/4"L x 1"D x 1-5/8"W. Output terminated in right angle 2.5/5.5mm barrel jack with 9mm shank. Complete with (MB973) plug in line cord. This power supply can be adapted to a multitude of applications.

12VDC/4.16AMP. Symbol Technologies p/n TR9CE4100LCP-A. Model 50-14000-075. UL/CSA plus approval for 4 other countries (CE). Level 3. Input 100-240VAC/50/60Hz. Made in Taiwan. 5-3/4"L x 2-1/2"W x 1-1/2"H. Standard IEC 3-prong socket for line cord. 5' output cord is terminated in 2.5/5.5mm barrel jack with 10mm shank. Center positive. Weight is 1 lb. Supplied less line cord.

5.7VDC/700MA. Philips 1128. Switching type wall transformer (also marked "fast travel charger"). Philips model 1128/SKU24769 Input; 90-132VAC 60Hz. UL/CSA. Class 2. Tiny size; 2-7/8"L x 2"H x 1-3/8"W. Made in China. Output cable is terminated in what appears to be a 3.5/1.1mm barrel jack. Center positive. 15,000 more available.

4.7VDC/2 AMPS. Philips 26092. "Fast travel charger". Input; 95-240VAC, 47 to 63Hz. UL/CUL. USA style AC prongs. (Slide on prongs are exchangeable) Small size; 4"L x 2-1/4"W x 1-1/4"H. 7 conductor output cable is 3/16" diameter and terminated in special Philips style flat plug. 50/carton. Currently equipped with USA wall prongs - but can be changed to foreign prongs.

Input; 100-125/200-240VAC 1.0/0.5A 50/60Hz. Branded AT&T. Four outputs; +5VDC/1.9A, +8VDC/1.1A, +15VDC/360ma, -15VDC/90ma. CSA plus approved for use in 3 other countries. (also bears #91-50792) CSA level 3 power supply. 6-1/2"L x 3"W x 2-3/8"H. Output cable terminated in special AT&T plug. Requires standard IEC type line cord (not supplied). Made in Malaysia

12VDC/2.1AMP (25 watts) Input; 100-240VAC, 50-60Hz. 2% line regulation. Manufactured by ITE. Low profile shape; 4-1/8" x 1-5/8" x 7/8" thick. weighs only 4.6 oz. Complete with AC cord. Output cord terminated in a 5.0/2.5 mm barrel jack with 9 mm shank. Center positive. Ideal for notebook computers and general applications.

15VDC/3AMP. SYS2011-4515. These power supplies are replacement units for Toshiba PA2450U & PA2484U. We have been told that this power supply will also work with the following laptops: SATELLITE: 220 225 440 460 470 480 490 1555 2100 2140 2180 2210 2590 2615 2655 2675 2715 4000 4010 4020 4030 4060 4080 4100 series, PORTEGE: 7000 7010 7020 7140 7200 and TECRA: 520 530 550 8000 700 710 720 730 740 770. Input 100 to 240VAC 50-60Hz. Level 3. cUL/CE/LPS/TUV/GS. 3-7/8"L x 2-1/2"W x 1-5/16"H. Requires non polarized line cord. (our MB973) Output cable terminated is filter equipped and terminated in 6.3/3.0mm barrel jack with 12mm shank. Center positive. Made by I.T.E. in China. Imported for ongoing availability. Contact Ted Duskes for quantity pricing.

16VDC/3.75AMP These power supplies are replacement units for many of the brand name laptops and notebooks currently in use. Series SYS2011-6016 - Input 100-240VAC 50-60Hz. 80-120VA. Level 3. UL/CSA/CE/LPS/GS and other approvals. 3-7/8"L x 2-1/2"W x 1-5/16"H. Requires non polarized line cord. (our MB973) Output cable terminated in black tipped 2.5/5.5mm barrel jack (with filter). Center positive. Made by I.T.E. in China. Imported for ongoing availability. Contact Ted Duskes for quantity pricing.

5VDC/2.4 Amp. UL/CSA. CUI Stack Model DSA-0151A-05A, p/n DPS050240-P5. Input; 100-120VAC 50/60Hz, 0.4A FCC tested to comply with standards for home or office use. Level 3. I.T.E./L.P.S. 3"L x 1-1/4"H x 2"W. Terminated in 5.5/2.1mm barrel jack 9mm long. Center positive. Made in China. Individually cartoned.
