Symbol Technologies

16VDC/700MA. Symbol p/n 54410-00-00. James 13932. UL. 3 prong grounded AC plug. 2-5/8"W x 3"L x 1-7/8"H. 2.5/5.5mm barrel jack with 9mm shank. Center positive.

12VDC/1A & 5.1VDC/600MA. Symbol Technologies p/n 50-04000-041 also T66R-M885-A4/SY. For the LS3070. Input; 120VAC/60Hz. 40W. UL/CSA. 5' line cord is terminated in a 3 prong AC plug. 6' output cord is terminated in 8 pin socket. Set top case is 6"L x 3"W x 3"H. Class 2. Individually cartoned. Made in Thailand.

12VDC/1A & 5.1VDC/600MA. Symbol Technologies p/n 50-14000-018. UL/CSA. 5' line cord is terminated in a 3 prong grounded AC plug. 6' output cord is terminated in 8 pin socket. Connections provided. Set top case is 6"L x 4"W x 2-1/2"H. Class 2. Made in Thailand.

12VDC/1A & 5.1VDC/600MA. Symbol Technologies p/n 50-14000-040 James Electronics model IE6410. Input; 230VAC/50Hz. CE/GS approved. Double-pole neutral fusing. 5' line cord is terminated in a 3 prong grounded AC plug. 6' output cord is terminated in 8 pin socket. Set top case is 5"L x 3-1/2"W x 2-1/2"H. Made in USA.

6.5VDC/1.5 AMP. Symbol p/n 59367-00-00. UL/CSA. Desktop unit with 5' line cord terminated in 3 prong grounded AC plug. 6' output cord is terminated in oddball plug. Class 2. Made in USA. Case size is 4-3/4"L x 3"W x 2-1/8"H.

12VDC/1A & 5.1VDC/600MA. Symbol Technologies p/n 50-04000-033. RU/CSA. 5' line cord is terminated in a 3 prong grounded AC plug. 6' output cord is 4 conductor stripped and tinned. Set top case is 6"L x 4"W x 2-1/2"H. Class 2. Made in China.

12VDC/1.2 AMP. Symbol Technologies T60R-J1200-6/MS model# 59842-00-00. UL/CSA. Desk top unit with 3 prong grounded AC plug on the end of a 5' line cord. The 6' output cord is terminated with a 2.5/5.5mm barrel jack with a 12mm shank. Center positive. Case is 5-5/8"L x 3"W x 2-1/4"H. Class 2. Made in Thailand.

12VDC/1A & 5.1VDC/600MA set top computer power supply. Symbol Technologies P/N T66R-M885. Also bears P/N 50-04000-033. 120VAC/60Hz input. UL/CSA approved. 6"L x 3"H x 3"W. Case has 4 plastic feet. 5' output 4 conductor cord is stripped and tinned. Line cord is terminated in standard 3 prong AC plug. Made in Thailand. Individually cartoned.

12VDC/1.2AMP. Symbol Technologies 50-14000-068 Rev. A Also bears P/N T60R-J1200-AM/SY Input; 120VAC/60Hz. UL/CSA. Desk top unit with 3-prong grounded AC plug on a 5' line cord. The 6' output cord is terminated in a special 4-pin socket. 4-3/4"L x 3"W x 2-1/2"H. Case has 4 plastic feet. Made in Thailand.

15VAC/2.5AMP. Symbol Technologies 60153-00-00. Also bears P/N T57152500H020G. 3-1/4"L x 2-1/2"W x 2-1/8"H. Input; 120VAC/60Hz. 46W. UL/CSA. 3-prong AC plug. output cord terminated in 5-pin Din plug (180 degree). Made by Ault in China.

5.1VDC/1.5 Amps. Symbol 50-14000-006. SAC R6D005-150. UL/CSA. Class 2. 5-3/4"L x 2-1/2"H x 2-3/4"W. High quality screw assembled case. Individually cartoned. Made in Taiwan. 5' output cord is terminated in 3-pin "DB" plug.

12VDC/1.2 AMP Symbol Technologies TI60R-J1200-O/SY. Model 50-04000-044. UL/CSA. Desk top unit with 5" line cord terminated in IEC male connector, which accepts standard IEC computer cable (our TH716). 6' output cord terminated in a 3.5mm mini phone plug. 4-1/2"L x 3"W x 2-1/4"H. Case has 4 plastic feet. Approved for 3 countries. Made in Taiwan.

12VDC/1.2AMP Symbol Technologies TI60R-J1200-O/SY. Model 50-04000-044 Rev. A . Input 230VAC/50Hz. Approved for use in 4 countries. Desk top unit with 5" line cord terminated in IEC connector. 6' output cord without connector. 4-1/2"L x 3"W x 2-1/4"H. Case has 4 plastic feet. Approved for 3 countries. Made in Hong Kong.

12VDC/1.2AMP. Symbol Technologies T60R-J1200-O/2SY model 50-04000-043. UL/CSA. Desk top unit with 3-prong grounded AC plug on a 5' line cord. The 6' output cord is terminated in a 3.5mm mini plug with positive tip. 4-1/2"L x 3"W x 2-1/4"H. Case has 4 plastic feet.

12VDC/1.2AMP Symbol Technologies T60R-J1200-o/2sy. Model 50-04000-052. UL/CSA. Desk top unit with 3-prong grounded AC plug on a 5' line cord. 6' output cord is stripped and tinned. 4-1/2"L x 3"W x 2-1/4"H. Case has 4 plastic feet.

6VDC/500MA. Symbol Technologies #50-14000-002 Rev.A. UL/CSA. Output cord terminated in 5.0/2.1mm barrel jack with 9mm shank. Center pos.

11VDC/600MA. Symbol Technologies #50-04000-086 Rev.B. UL/CSA. 3-prong grounded AC plug. 6' output cord terminated in 5.5/2.1mm right angle barrel jack. Center neg.

15VDC/2.5AMP output set top power supply. Symbol Technologies p/n 50-14001-005 Rev B. Model ADP-5002-15V. (Smart Industries #91-58012) AC input; 100-240VAC. 50-60Hz. UL/CSA (Level 3) (N16502). Also approved for 6 other countries. High quality industrial grade construction. Size;4-3/4"L x 2-3/4"W x 1-1/2"H. Made in Malaysia. Accepts standard 3 prong IEC cord (not supplied). Output is to 6 contact Molex connector.

Symbol Technologies MC9000 power supplies. 12VDC/9AMP output. Symbol Technologies p/n 50-14001-004 Model SYM04-1. AC input; 100-120VAC/200-240VAC. 50 to 60Hz. 3.0A/1.5A. UL/CSA (Level 3) (N16601) . Also approved for Switzerland and 4 other countries. Built-in fan. High quality industrial grade construction. Unit has internal voltage control pot which allows output voltage level control, but we do not know its +- range. Nominal output is 12VDC, highly regulated. Built in cooling fan. Case is 7"L x 3-3/4"W x 2"H. Accepts standard IEC power cord. (Not supplied) Output is to Molex connector (not supplied) - matching molex parts numbers to make connector (not supplied) are: 1x15-04-9342 Strain Relief, 6x 44476-3112 Minifit Jr Female Terminal, 1x 39-01-2065 Mini Fit Jr Receptacle Dual Row 6 Circuit Made in Malaysia. Individually cartoned. Original OEM cost from Symbol Technologies $75. Call Ted at 1 800 341 6468 to discuss your quantity requirements. Shipping Weight 2.25 pounds.

24VDC/4.5AMP output. Symbol Technologies p/n 50-14001-009. Model SYM04-3. (Smart Industries #91-58090) AC input; 100-120VAC/200-240VAC. 50 to 60Hz. 3.0A/1.5A. UL/CSA (Level 3) (N16601) . Also approved for Switzerland and 4 other countries. High quality industrial grade construction. Unit has internal voltage control pot which allows output voltage level control, but we do not know its +- range. Nominal output is 24VDC, highly regulated. Built-in cooling fan. Case is 7"L x 3-3/4"W x 2"H. Accepts standard IEC power cord (not supplied). Output is to Molex connector - matching molex parts numbers to make connector (not supplied) are: 1x15-04-9342 Strain Relief, 6x 44476-3112 Minifit Jr Female Terminal, 1x 39-01-2065 Mini Fit Jr Receptacle Dual Row 6 CircuitWe can supply a short cable assembly (2 grounds and 2 x 24VDC+) on the matching Molex connector - our part number TH509. Made in Malaysia. Weight: 2.2 pounds. Individually cartoned.

Symbol Technologies model 50-14000-053, CE/DVE certified power supplies. These brand new power supplies accept 230VAC/50Hz, 0.25A and output; +5.1VDC @ 1.0A, +6.5VDC @ 1.0A and -12VDC @ 0.1A. Housed in set top black housing with 4 rubber feet. 3 3/4" W x 6 1/4" L x 2 1/2" H. The 6" AC cord is terminated in 3 prong male IEC connector. The 5' output cord is terminated in a 5 pin din plug. Made in China.

Symbol Technologies 50-14000-023 set top power supply. p/nT157R-08500-ES/SY. 230VAC/50Hz 50mA input. Output 8VDC @ 500mA. CE and three other foreign listings. 6" line cord terminated in 3 prong male IEC connector. 5' output cord terminated in 3 pin special connector. Dimensions are 2 1/8" H x 3 3/8" L x 2 5/8" W. Made in Thailand.

Brand new Symbol Technologies Inc. #50-14001-010 multi output power supply. Input; 100 to 240VAC at 50 to 60 Hz, 2.0A, 22W. UL/CE and other foreign approvals. Outputs; +5VDC @ 1.0A, +12VDC @ 1.2A and -12VDC @ 0.2A. This unit has no cables attached to it but uses a standard 3 prong IEC line cord (NOT SUPPLIED). In nice set top case with four rubber feet. Measures 4 5/8" L x 2 3/4" W x 1 1/2" H. The unit bears the following part numbers; 50-14001-010, ADP-4702-M3, 91-58014. There is a 6 pin molex output connector on the side of the case. (Our TH509 molex plug mates with this connector and may be ordered for $5.90 each in 10 lot). Made in Malaysia. We have 170 more available.

Symbol Technologies model 50-14000-046 REV C, CE/GS certified power supply. These brand new power supplies accept 230VAC @ 50Hz and outputs +12VDC @ 1.0A. Each unit is black, measures 3 3/4"W x 6 1/4"L x 2 1/2"H. Six inch AC cord is terminated in a 3 male pin IEC connector allowing for the connecting of any line cord with a plug to suit the country of use. Five foot output cord is terminated in a 4 pin din plug (only two pins are used). Made in China.
