Excella STX offers a viable and affordable alternative to implement image capture at the earliest entry points for check payments. Excella STX, USB interface. Prints on check back only .
Manufacturer: MagTek
Weight: 8Lbs
MICR Reading:
E13B or CMC7
MICR Data formats compatible with previous MICR readers and scanners from MagTek
Image Scanning:
Captures front and back image of check
Resolution: 200 dpi (scaling to 100 dpi)
Image rendition: black/white, grayscale, color
Image compression: CCITT G4 (black/white) or JPEG (grayscale)
Image files: TIFF 6.0, JFIF with EXIF tags, BMP
Image storage memory: optional thru standard storage memory devices
Single-side ID Scanning: alternate entry to scan standard ID cards
Image Quality:
Image quality reporting
Image Security:
Digital signature for image file authentication
Document Handling:
Single feed
Printing:
Franking (front of the check) and endorsing (back of the check)
Stationary ink jet printer; message height: 1/8” consisting of 12 pixels
Prints horizontal message; message is programmable
Internal fonts available; support for downloadable bitmap fonts
Card Reading:
Optional 3-Track magnetic stripe reader with MagnePrint®
Interfaces:
USB 2.0; USB 1.1 compatible
Ethernet 100baseT
Interfaces and API compatible with Excella
Operational features:
Reads MICR before endorsing; MICR data can be evaluated before endorsing
Front scanning before franking; printed message can be excluded from front image
Easy access to scan bars, printer cartridges, and check path
Visible LED indicators to provide visual device status
Alignment sensors to ensure proper check feeding; LED’s will indicate proper check entry
